Magnetic drum is automatic equipment for ferrous separation widely used in high volume applications because self-cleaning is continuous. Unlike the pulley, it is not install instead of the original roller conveyors and the conveyor belts, but in the outputs of these conveyors, pipe outputs, silos, mills, etc.
In addition to being very effective in eliminating particles of ferrous merchandise, it helps protect plants, crushers, etc. Possible parts/pieces that come out of the machines or even mix with the material.
Application Of Magnetic Drums
Since it is complete, automatic, and very efficient equipment, magnetic drums are used in various types of industries, including plastics, rubbers, metals, mines, transformation and containers, pharmaceutical products, chemical products, etc.
Global concern increases every day with the recycling of materials and residues. The separator is of great importance in this process, the separation of ferrous materials in aluminum, construction residues, paper, protection. Factories, crushers, and crushers.
Magnetic Drum Operation
The magnetic drum separator formed by a stationary magnetic system and a swivel housing with fins. When the raw material falls on the drum, the ferrous particles are preserved in the magnetic part, and the raw material of ferrous particles follows the flow of the production line.
As is a rotating housing, the retained particles dragged by the fins of the housing until they leave the area of action of the magnetic field, falling into an isolated reservoir of the raw material.
As it is an automatic separation team, it does not require the intervention of the operator for cleaning, which makes the system much more efficient.
Technical Specification Of The Magnetic Drum
MAGTEK manufactures custom magnetic drums in different dimensions and formats, depending on the client’s application. Built-in stainless steel case, the magnetic system may consist of ferrite or neodymium magnets.
The magnetic drum can supply with a built-in carbon or stainless steel box, with a drum or more with a crossed magnetic fields, which increases the efficiency of ferrous separation in the process. In this model with box, it has a continuous speed coupled engine or with optional speed control.
In addition to all magnetic and electromagnetic equipment with cardiac stimulators and metallic prostheses. They must maintain their distance from this equipment. Be careful when handling tools and/or metal parts near magnetic material so as not to cause accidents.
The magnetic drum is ideal for the separation of ferrous residues and particles that may exist in dry products through a gravitational fall process.
The magnetic drum commonly used in conveyor belts for grain industries and several other agricultural and food areas.
The mining, plastics, and recycling industries also benefit from the use of magnetic drums, especially in the extraction of sand. Container cement, decontamination, and recycling of plastic residues.
The operation is simple. The front part of the drum contains the magnetic field that attracts ferrous. Contaminations are rejecting when they pass through the subsequent non-magnetic portion.
When the outer casing of the rotation of the magnetic drum. Which carries the contaminations at the lower elimination point and the decontaminated material. Is generating a path in the conveyor. Due to its construction form, our has a low magnetic loss. High energy consumption, and reduced loss by its traction engine.
